RS (Revolutionary Sliding) Technology for CNC lathes

The FMB Turbo 3-38 for sliding headstock CNC lathes features RS (Revolutionary Sliding) Technology that fully supports the bar pusher and stock from inside the bar feeder all the way into the lathe spindle.

The FMB Turbo 3-38 RS will be for Swiss lathes with longer Z-axis strokes, demanding applications such as non-guide bushing mode, challenging materials, and profiled stock. The integrated and oiled sliding guide module and moving steady-rest provide superior bar pusher and stock support in the transition zone between the bar feeder and lathe spindle. RS Technology eliminates the need for telescopic noses, extended pushers, and Z-axis axial track, which were accessories designed to minimize the gap between the bar feeder and lathe. The new patented design reduces vibration and significantly boosts maximum rpm.

The Turbo 3-38 RS will help manufacturers achieve faster cycle times, better surface finishes, and tighter tolerances.

How does RS Technology work?

Instead of the telescopic nose device connecting the machine tool and bar feeder, the bar feeder uses RS Technology. A steady rest mounts directly to the back of the machine tool’s headstock, providing material support at the back of the spindle, while an extension tube or guide module (what could be considered a sliding spindle liner) is internal to the bar feeder. As raw material travels, the integrated and oiled sliding guide module and moving steady rest provide superior bar pusher and stock support in the transition zone between the bar feeder and lathe spindle.

Edge Technologies
https://edgetechnologies.com
